D101A - Straight Dowel Bar Splicer

Accessories

Dayton

The Dayton Superior Dowel Bar Splicer is a one-piece unit, integrally forged from ASTM A615 grade 60 deformed rebar material. The splicers are available in #4 through #11 rebar sizes to be used in conjunction with the corresponding size dowel-in to accomplish a mechanical splice designed to achieve 160% of specified yield (full mechanical ultimate). The splicer can be furnished straight (D101A) cut to length, 90° and 180° hooked (D102A and D103A) and double-ended (D104A) in plain or epoxy coated finish. The splicer can also be special-ordered with a reduced diameter washer flange or with the washer flange clipped (in more than one direction, if required) to provide adequate concrete cover, or to avoid interference. The D104A Double-Ended Dowel Bar Splicer is used to establish a direct load path through a concrete section, thus avoiding multiple hooked rebar and eliminating rebar congestion. The double-ended unit can be configured in a “U” shape for special applications.

Pricing Information/Unit Sizes

Product Code	Packaging
78188	PLAIN 4 X 12"
78190	PLAIN 4 X 18"
78198	PLAIN 4 X 30"
78194	PLAIN 4 X 24"
78202	PLAIN 4 X 36"
78204	PLAIN 4 X 42"
78205	PLAIN 4 X 48"
144107	PLAIN 4 X 54"
78206	PLAIN 4 X 60"
144108	PLAIN 4 X 66"
78154	PLAIN 4 X 78"
144109	PLAIN 4 X 84"
144685	PLAIN 4 X 90"
144110	PLAIN 4 X 96"
144111	PLAIN 4 X 102"
144693	PLAIN 4 X 108"
144694	PLAIN 4 X 114"
144761	PLAIN 4 X 120"
144225	EPOXY 4 X 12"
78192	EPOXY 4 X 18"
78197	EPOXY 4 X 24"
78199	EPOXY 4 X 30"
78203	EPOXY 4 X 36"
124075	EPOXY 4 X 42"
143068	EPOXY 4 X 48"
144226	EPOXY 4 X 54"
78207	EPOXY 4 X 60"
144227	EPOXY 4 X 66"
144228	EPOXY 4 X 78"
144229	EPOXY 4 X 84"
144703	EPOXY 4 X 90"
144230	EPOXY 4 X 96"
144231	EPOXY 4 X 102"
144232	EPOXY 4 X 108"
144711	EPOXY 4 X 114"
144297	EPOXY 4 X 120"
