A21X - Flat Tie

Accessories | Wall Forming Accessories | Light Forming Products

Dayton
Dayton Superior A21X Flat Tie is used with the A51 Wedge Bolt to secure and space modular forms.
3,000 lbs. Safe Working Load
A21X ties are available in 6" through 24" in 1/2" increments. The wall thickness is stamped on each tie. Standard breakback is 1/4".
Product Code Packaging
13204 STANDARD - 3000 LBS SWL WALL SIZE - 4"
13206 STANDARD - 3000 LBS SWL WALL SIZE - 6"
143477 STANDARD - 3000 LBS SWL WALL SIZE - 7"
13208 STANDARD - 3000 LBS SWL WALL SIZE - 8"
101420 STANDARD - 3000 LBS SWL WALL SIZE - 9"
13210 STANDARD - 3000 LBS SWL WALL SIZE - 10"
13211 STANDARD - 3000 LBS SWL WALL SIZE - 11"
13212 STANDARD - 3000 LBS SWL WALL SIZE - 12"
121166 STANDARD - 3000 LBS SWL WALL SIZE - 13"
13214 STANDARD - 3000 LBS SWL WALL SIZE - 14"
101430 STANDARD - 3000 LBS SWL WALL SIZE - 15"
13216 STANDARD - 3000 LBS SWL WALL SIZE - 16"
13218 STANDARD - 3000 LBS SWL WALL SIZE - 18"
13220 STANDARD - 3000 LBS SWL WALL SIZE - 20"
101440 STANDARD - 3000 LBS SWL WALL SIZE - 22"
13224 STANDARD - 3000 LBS SWL WALL SIZE - 24”
101460 STANDARD - 3000 LBS SWL WALL SIZE - 28”
101470 STANDARD - 3000 LBS SWL WALL SIZE - 30”
101480 STANDARD - 3000 LBS SWL WALL SIZE - 36”
101490 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 6"
101500 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 8"
101510 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 10"
101520 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 12"
101530 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 14"
101550 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 16"
101560 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 18"
143478 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 30”
143479 HEAVY DUTY - 3500 LBS SWL WALL SIZE - 36”
Specific customer pricing may be available in Dayton Access. Minimum standard packaging sizes may apply.
